High-Speed Logistics Scale
1-60kg wide-range dynamic checkweigher with belt speed adjustable 5-120 m/min and ±10-20g accuracy, purpose-built for express and logistics sortation lines
High-Speed Logistics Scale (MQ-CW12080S60) — range 1-60kg, accuracy ±10-20g. Factory-direct from Guangdong, China. OEM & custom available.
Typical applications: Logistics parcel weighing (woven-bag soft packages, carton parcels, palletized cartons)
Key Features
- ✓High-speed conveyor belt designed for weighing logistics parcels
- ✓Powerful computing functions record all inspection data
- ✓Touchscreen operation with user-friendly design
- ✓Variable-frequency drive motor with speed adjustable as required
- ✓Tri-color light alarm for over/under-weight limits ensures strict in-line product quality control
Why Choose MQ-CW12080S60
Full 1-60kg Weighing Range
Checkweighing range of 1-60kg with 0.001kg display resolution — from a 1kg soft-pack mailer to a 60kg heavy carton, one machine handles it all. Parcel weights in logistics vary enormously; an undersized range forces you to split shipments across separate lines by weight. This unit covers the full span so you never have to.
Belt Speed Adjustable 5-120 m/min
A variable-frequency drive motor adjusts belt speed anywhere within 5-120 m/min. Crank it up during peak season to chase throughput, then match your conveyor line's normal pace the rest of the year. Whatever speed the upstream and downstream sections run, the checkweigher keeps step — it will never be your line's bottleneck.
Extended 1200×800mm Weighing Deck
The weighing section measures 1200mm long by 800mm wide, handling products up to 800×800mm. Woven-bag soft packs are irregular in shape and palletized cartons are bulky — on an ordinary checkweigher deck they overhang and weigh unsteadily. This extended deck lets large parcels settle fully on the platform, so the weight signal is captured completely and the accuracy actually holds.
±10-20g Dynamic Accuracy Stops Faulty Parcels On the Spot
Dynamic checkweighing accuracy of ±10-20g at the full 60kg range — enough to detect a dozen-gram difference in a sixty-kilogram load. A missing accessory or a wrong model shipped triggers an instant weight alarm, so the problem parcel is intercepted before it leaves the warehouse — not investigated on CCTV after a customer complaint.
Tri-Color Tower Light for At-a-Glance Line Status
A tri-color light signals pass, overweight and underweight in real time, visible from meters away on the line, working with upper/lower limit settings to keep outbound weights under tight control. On short-staffed night shifts, a light you can see from anywhere beats a screen someone has to watch.
Pusher, Swing-Arm or Diverter-Wheel Rejection
Three rejector types match different parcel profiles: a pusher for rigid cartons — quick and decisive; a swing arm for soft bags — large contact surface, no jamming; a diverter wheel for smooth high-speed diverting without tipping packages. Specified to your actual cargo type, so rejection stays clean and good parcels never get knocked over on the line.
Problems It Solves for You
Manual spot-checking on express sortation lines means a static scale stops for every parcel it weighs. At thousands of parcels per hour during peaks, full inspection is impossible — overweight parcels slip through, only surface at line-haul, and the freight disputes all land on you.
In-line dynamic weighing checks parcels without stopping them. With belt speed up to 120 m/min the checkweigher matches your sortation pace, 100% inspection replaces sampling, over/underweight parcels are alarmed and rejected on the spot, and freight is settled on documented actual weights.
E-commerce warehouses rely on manual pre-shipment checks. A missing free gift or a wrong model packed is invisible to the eye — the customer complains after delivery, the platform fines you, you pay for reshipment, and one bad order wipes out the profit of three.
±10-20g accuracy turns 'one item missing' into 'a measurable weight gap'. As the final gate before dispatch, the machine automatically compares each parcel against its standard weight and pushes anomalies off the line for recheck — weight-based error-proofing instead of eyeball checks.
Woven-bag soft packs and palletized cartons are large and irregular in shape. On a standard checkweigher's small deck, half the parcel hangs off the edge — readings jump around and the data is unusable.
The 1200×800mm weighing deck is purpose-designed for large items. Soft packs, cartons and palletized loads up to 800×800mm sit fully on the platform, delivering stable, trustworthy weight data.
Weights get jotted on paper or not recorded at all. Come month-end reconciliation with customers or freight settlement with line-haul carriers, there is no record to show — nothing to prove, no way to settle the argument.
Built-in computing records every inspection metric, exported directly via USB. Every parcel's weight is on the books — hard evidence for reconciliation, traceability and freight settlement.
Technical Specifications
| Product model | MQ-CW12080S60 |
|---|---|
| Display division | 0.001kg |
| Inspection weight range | 1-60kg |
| Weight checking accuracy | ±10-20g |
| Size of weighing section | L 1200mm*W 800mm |
| Suitable product size | L≤800mm; W≤800mm |
| Storage formula | 1种 |
| Belt speed | 5-120米/分钟 (5-120m/min) |
| power supply | AC220V±10% |
| Shell material | 碳钢喷漆 (Carbon steel spray painting) |
| data transmission | USB数据导出 (USB data export) |
| Sorting section | 标准1段 (Standard 1 section) |
| Elimination method | 推杆式、拨杆式、摆轮可选 (Push rod, toggle, and balance wheel options are available) |
| Optional Features | 实时打印、读码分拣、在线喷码、在线读码、在线贴标 (Real time printing, code reading and sorting, online code spraying, online code reading, and online labeling) |
Functions in Detail
Rejection matched to your cargo type
Three rejector options come as standard choices: pusher, swing arm and diverter wheel. The pusher suits regular cartons — direct stroke, decisive action. The swing arm suits woven bags and soft packs — large contact area that won't deflect the parcel. The diverter wheel suits continuous high-speed diverting — smooth transitions, no tipped parcels. Tell us your cargo type and weight distribution and we will match the right configuration.
Data recording and export
Built-in computing automatically logs inspection statistics — total checked, passed, over/underweight counts — with live on-line tallies, exportable via USB for daily reports, monthly reconciliation and quality traceability. Stores 1 product recipe, ideal for logistics operations running a single cargo class in continuous high volume: power on and run, no constant re-tuning of parameters.
Touchscreen operation and variable-speed drive
A touchscreen HMI puts limit setting and speed adjustment directly on screen — operators are proficient after brief training. The motor is VFD-controlled with belt speed continuously adjustable within 5-120 m/min, so matching upstream and downstream conveyors requires no mechanical drive-part changes; speed changes are done entirely on screen.
Construction and power supply
The housing is painted carbon steel, suited to dry indoor environments such as logistics warehouses and sortation centers, with the structural rigidity to carry 60kg-class heavy goods without deformation. Power is AC220V±10% from ordinary mains; minor voltage fluctuation does not affect weighing stability and no dedicated power modification is needed on site.
Optional function extensions
Five options are available to suit your operation: real-time printing, barcode-reading sortation, in-line inkjet coding, in-line code reading and in-line labeling — integrating weighing, coding, labeling and sorting on one conveyor section. Customers planning an integrated DWS retrofit can specify requirements at order time, with everything integrated and commissioned before the machine leaves the factory.
Industries & Application Scenarios
Integrated into sortation conveyors for in-line weighing of inbound and outbound parcels. Belt speed is tuned to match the sorter, overweight parcels are auto-rejected for recheck, and weighing data exports via USB for freight reconciliation with branches and line-haul carriers.
Weight verification at the end of the outbound packing line, comparing against order standard weights to intercept short-packed or mis-packed parcels. Optional in-line labeling and real-time printing complete weighing and waybill work in one station.
Mixed-client cargo shipping on one line: the 1-60kg wide range covers everything from small soft packs to heavy cartons, and optional barcode-reading sortation diverts parcels by code — one line serving multiple cargo owners.
Palletized cartons and full-case goods are weighed before leaving the factory to verify case counts are complete. The tri-color light flags underweight cases, keeping short-shipped goods out of customers' warehouses and complaints off your desk.
In-line checkweighing of woven bags right after filling. The widened deck accommodates the irregular shape of soft packs, the swing-arm rejector handles soft bags without jamming, and bags with large filling deviations are stopped before truck loading.
Own Factory · Seeing Is Believing
Guangdong Miqi designs, builds and tests every machine in-house — each unit is bench-tested before shipment. Free sample testing, on-site factory visits and live video of the running machine are all welcome.
