Automatic Scanning, Weighing, Instant Printing and Labeling Machine for Enameled Wire
Weigh, scan, print and label spools from 10g to 50kg in one pass — weight data flows straight into MES/ERP for pay-by-weight billing
Automatic Scanning, Weighing, Instant Printing and Labeling Machine for Enameled Wire (MQ-MLW4030L50) — range 10g-50kg, accuracy ±0.5-2g. Factory-direct from Guangdong, China. OEM & custom available.
Typical applications: Enameled wire, coils, and carton-packed goods
Key Features
- ✓Memory storage for up to 100 parameter sets
- ✓Dynamic barcode/QR code generation with adjustable printing speed
- ✓MES and ERP system integration, supporting distribution-center price calculation and more
- ✓Integrated label template editing software allows fully customizable label content
- ✓Height-adjustable applicator head suits different production lines
- ✓Multiple labeling modes available to meet instant labeling needs for different applications and products
- ✓Automatic adjustment of product information, printer, label position, and label rotation to suit different products and production lines
Why Choose MQ-MLW4030L50
Weigh, print, label in one pass
The moment a product hits the scale, it is weighed, a barcode/QR code is generated on the fly, printed instantly and applied automatically — at 15-25 pcs/min. No more copying weights by hand or writing labels: weight and label content are encoded in one step, eliminating transcription and mislabeling errors at the source.
One machine covers 10g to 50kg
Checkweighing range 10g-50kg with 0.001kg readability and ±0.5-2g accuracy. From small coils to full cartons of enameled wire, everything goes on one scale. The 500×300mm weighing section handles spools and cartons up to 300mm per side — no need for separate scales per product size.
Weight data straight into MES/ERP
The measured weight of every spool uploads to your MES/ERP in real time, supporting pay-by-weight pricing at distribution centers; USB export is also available for archiving. For customer reconciliation or factory audits, one scan reveals origin and net weight — no digging through paper records.
100 recipes for one-touch changeover
Store weighing and label parameters for different wire gauges and spool types as recipes — up to 100 sets, recalled instantly at changeover. Label template editing software is included: edit any field or layout yourself, no waiting on the manufacturer.
Adjustable head — fits existing lines
The print-and-apply head adjusts vertically to match your existing conveyor height. Product info, printer, label position and label rotation adjust automatically, with ±5-10mm labeling accuracy and multiple application methods to choose from. Switching lines requires no major rework.
Rugged 304 stainless steel body
The housing is 304 stainless steel — it shrugs off shop-floor oil and daily wipe-downs without rusting. Power is AC220V±10%, tolerant of factory grid fluctuation: plug into a standard workshop outlet and run, no dedicated power upgrade needed.
Problems It Solves for You
Enameled wire is billed by weight, but manual reading and handwritten labels keep getting net weights wrong or spool numbers mixed up — leading to reconciliation disputes, returns and claims.
After weighing, a barcode/QR code is generated, printed and applied automatically. Weight and ID are encoded onto the spool in one step with zero manual transcription — nothing to get wrong.
One line runs dozens of wire gauges and spool types. Every changeover means re-entering parameters and re-laying-out labels — half a day lost each time, and the more fragmented the orders, the bigger the loss.
100 stored recipes recalled on demand; edit label fields yourself with the template software, while product info, label position and rotation adjust automatically.
Weighing, printing and labeling take three stations and three workers whose cycle times never match — and in peak season you struggle to hire yet still overstaff this step.
Scanning, weighing, printing and labeling integrated in one machine running continuously at 15-25 pcs/min. One operator supervises; the rest of the crew moves to other processes.
Customer audits demand per-spool weight traceability, but finding one order in paper records takes half a day — and a missed record means a nonconformity.
Weight data uploads to MES/ERP in real time or exports via USB for archiving. Every spool's net weight is code-linked and retrievable on demand.
Technical Specifications
| Product model | MQ-MLW4030L50 |
|---|---|
| Display division | 0.001kg |
| Inspection weight range | 10g-50kg |
| Weight checking accuracy | ±0.5-2g |
| Size of weighing section | L 500mm*W 300mm |
| Suitable product size | L≤300mm；W≤300mm |
| Storage formula | 100种 |
| Labeling speed | 15-25pcs/min |
| power supply | AC220V±10% |
| Shell material | 不锈钢304 Stainless steel 304 |
| Labeling accuracy | ±5-10mm |
| data transmission | USB数据导出 USB data export |
| Optional Features | 实时打印、读码分拣、在线喷码、在线读码、在线贴标 |
Functions in Detail
Application methods & head adjustment
The print-and-apply head adjusts vertically to suit conveyor lines of different heights. Multiple application methods handle spools, cartons and other items for on-the-spot labeling. The machine automatically adjusts product info, printer, label position and label rotation, with ±5-10mm accuracy — no manual realignment at changeover.
Label editing & barcode generation
Integrated label template editing software lets you lay out weight, ID, date and any other fields freely. Barcodes/QR codes are generated dynamically from measured data, and print speed is adjustable to keep pace with the 15-25 pcs/min labeling rate. Label redesigns never require outside help.
Data management & system integration
Connects to MES and ERP systems with real-time weight upload — usable for pay-by-weight pricing at distribution centers. Plants without a host system can export via USB for periodic archiving. Memory storage holds 100 product parameter sets for changeover recall, covering both data and recipes.
Optional feature expansion
Five options are available as your line demands: real-time printing, code-reading sortation, inline coding, inline code reading and inline labeling. Grow from simple weigh-and-label to code verification and code-based sorting — one machine upgrades step by step with your line, no full replacement.
Construction & installation requirements
304 stainless steel housing resists oil and withstands wipe-downs. Weighing section L500×W300mm suits products up to 300mm in length and width. Power AC220V±10% connects to ordinary workshop mains — no three-phase supply or dedicated power work; wire it up on arrival and start production.
Industries & Application Scenarios
Spools are weighed automatically as they come off the line; net weight becomes a barcode applied on the spot. Ship by weight-based pricing with data uploaded to ERP for automatic settlement — shipping documents match physical weights one-to-one.
Finished winding coils are weighed and tagged with traceability codes. Weight anomalies directly flag copper usage or turn-count issues; ±0.5-2g accuracy stands guard, and assembly scans the code to trace any coil's origin.
Reels and copper coils are labeled by actual measured weight before warehousing. The 10g-50kg range covers small coils to full reels; stocktaking becomes scan-and-count — no more estimated weights on the books.
Cartons pass over the scale before dispatch and receive shipping labels instantly. Boxes up to 300mm per side and 50kg go straight on the line, catching shortages and short-packs before they leave the factory.
Parcels are weighed and scanned in-line, priced automatically by weight and labeled. Optional code-reading sortation routes parcels by destination — billing and weighing in one step.
Own Factory · Seeing Is Believing
Guangdong Miqi designs, builds and tests every machine in-house — each unit is bench-tested before shipment. Free sample testing, on-site factory visits and live video of the running machine are all welcome.
Frequently Asked Questions
What is the price of Automatic Scanning, Weighing, Instant Printing and Labeling Machine for Enameled Wire (MQ-MLW4030L50)?+
Pricing depends on rejection type, number of weighing sections and options (printing, barcode reading, labeling). MIQI is the manufacturer — send your product weight, size and line speed for a same-day factory-direct quotation via WhatsApp +86 133 7765 0530 or the inquiry form.
Does MIQI export weigh-price labeling machines worldwide?+
Yes. We ship worldwide with export wooden-case packing, full English documentation, and voltage built to your country's standard (220V/380V, 50/60Hz). Remote commissioning support via video call; OEM branding welcome.
Tell Us About Your Product
Share your product weight range, dimensions and line speed — our engineer replies within 24 hours with model recommendation and quotation.
